Working Principle of Dual Servo Spinning Welding Machine

The dual servo spinning welding machine operates based on the principles of friction heating and plastic melting, achieving high-precision motion control through a dual servo motor system. During operation, one servo motor drives the upper mold (or workpiece) to rotate at high speed, while another servo motor precisely controls the axial pressure and feed speed, ensuring that the surfaces of two circular plastic workpieces to be welded come into close contact and generate relative friction. In the process of friction, mechanical energy is converted into thermal energy, rapidly heating the plastic surface to a molten state. Subsequently, the servo system precisely controls the rotation stop and hold time, allowing the molten plastic to fully fuse under pressure. After cooling and solidification, a high-strength weld joint is formed. This process is monitored and adjusted in real-time by the PLC control system to ensure the stability and consistency of welding quality.

Comprehensive Introduction

The dual servo spinning welding machine is a welding equipment that integrates high precision, flexibility, and intelligence. Compared to traditional pneumatic or single servo welding machines, its dual servo drive system achieves independent and precise control of rotational speed and axial pressure, effectively avoiding issues such as false welding and overflow, with a welding yield rate of over 99%. The equipment supports welding circular workpieces with diameters ranging from 10mm to 500mm. Through modular design and parameterized programming, it can quickly switch between different product processes to adapt to diverse production needs. In addition, the equipment is equipped with an intelligent touch screen and a data monitoring system, supporting the storage of process parameters, traceability of production data, and fault prediction functions. Combined with automated loading and unloading integration, it significantly improves production efficiency and management level, making it a core equipment for modern manufacturing to achieve efficient and stable welding.

Application Industries

1. Automotive Industry: Used for welding various circular plastic components in automobiles, such as car filter housings, which ensure the sealing of the filtration system and prevent impurities from entering critical parts like the engine; car fuel tanks require extremely high airtightness and strength to ensure the safety of fuel storage and transportation; as well as antifreeze pots, intake manifolds, etc., which can meet the usage requirements of automotive components under complex working conditions through welding by dual servo spinning welding machines.

2. Medical Industry: Widely used in the production of medical consumables, such as the welding of syringe bodies and pistons, infusion connector joints, dialysis filter housings, etc. Medical products have extremely high hygiene and safety requirements. The welding process of dual servo spinning welding machines is pollution-free and ensures the sealing and strength of the welded parts, avoiding liquid leakage and meeting the strict quality standards of medical products.

3. Electronics Industry: Suitable for welding various circular plastic components of electronic products, such as circular battery housings, which require sealing after welding to prevent electrolyte leakage; waterproof connectors ensure waterproof and dustproof performance in various environments; the plastic casings of wearable devices like smartwatches and bracelets are welded through high-precision welding to achieve a combination of aesthetics and functionality.

4. Home Appliance Industry: Commonly used for welding key components of home appliances, such as the balance ring of washing machines, whose welding quality directly affects the stability and quietness of the machine's operation; water purifier filter cartridge housings are welded to ensure the sealing of the filter cartridges and improve filtration efficiency; steam valves of rice cookers and dust cups of vacuum cleaners are welded through dual servo spinning welding machines to enhance product durability and quality.

5. Packaging Industry: For the welding of circular packaging containers such as cosmetic bottles, food sealing cans, and lubricating oil drums, dual servo spinning welding machines can achieve high-speed and efficient welding. Ensuring the sealing of packaging containers extends product shelf life while meeting large-scale production demands and improving packaging production efficiency and quality.
